Technical Parameters
| Dimensions sliding table | 3000/3200x375mm | 3000/3200x430mm |
| maximum cutting panel length | 3000/3200mm | 3000/3200mm |
| maximum cutting panel thickness | 75mm | 75mm |
| Tilting angle saw blade | 0-45°mm | 0-45°mm |
| Saw blade diameter | Ø300mm | Ø300mm |
| Scoring saw blade diameter | Ø120mm | Ø120mm |
| Speed of main saw blade | 4500/6000rpm | 4500/6000rpm |
| Speed of scoring saw blade | 6000/8000rpm | 6000/8000rpm |
| Spindle diameter | Ø30mm | Ø30mm |
| Spindle of scoring saw diameter | Ø20mm | Ø20mm |
| Main motor power | 5.5Kw | 5.5Kw |
| Scoring power | 0.75Kw | 1.1kw |
| Weight | 750kg | 900kg |
| Voltage | 380v/50hz 3phase | 380v/50hz 3phase |
| Body packing size | 2150*1100*1100mm | 2150*1100*1100mm |
| Table packing size | 3250*500*400mm | 3250*500*400mm |
