Technical Parameters
| Max. working width | 630mm | 500mm | 400mm |
| Max. working thickness | 180mm | 180mm | 180mm |
| Min.working thickness | 5mm | 5mm | 5mm |
| Min. working depth | 220mm | 220mm | 220mm |
| Max. cutting depth | 5mm | 5mm | 5mm |
| Cutter head spindle | 5000r/min | 5000r/min | 5000r/min |
| Feeding speed | 6.5m/min | 6.5m/min | 6.5m/min |
| Main motor | 7.5kw | 4kw | 3kw |
| Machine weight | 600kg | 500kg | 420kg |
| Sanding belt linear speed | 9m/sec |
| Spindle speed | 1420r/min |
| Main spindle power | 4kw |
| Oscillation motor power | 0.025kw |
| Sanding belt size | 3120*170mm |
| Dust outlet diameter | +100mm*2c |
| Overall size | 1800*620*l00mm |
