Technical Parameters
| Sawing length and width | 3100*3280mm |
| Sawing speed | 0-80mm |
| Feeding speed | 0-60m/min |
| Sawing height | 80mm |
| Steam floater power | 2.2kw |
| Main saw motor | 11kw |
| Feeding servo motor | 1.5kw |
| Reducer models | RV63 |
| sawblokc driver | 1.5kw |
| main blade spindle diameter | 30mm |
| the main blade dimeter | 350-400mm |
| vice blade spindle diameter | 25.4mm |
| vice saw blade diameter | 180mm |
| total weight | 4500kg |
| total power | 16.2kw |
| overall size | 5950*5650*1700mm |
