Technical Parameters
| Max. working speed | 90m/min |
| Max. engraving speed | 25m/min |
| Repeated positioning accuracy | +0.05mm |
| Carving instruction | G code |
| Voltage | 380V/50hz 3Phase |
| Spindle speed | 18000rpm/min |
| Transmission way | X/Y轴高精密1.5模斜齿传动、Z轴丝杠 |
| Guide | 台湾CSK Guide |
| Inverter | K&R7.5kw |
| Drive system | Servo motor |
| control system | Ncstudio system |
| spindle | HQD6.0KW*4 |
| Working table | Vacuum double table |
| Vacuum pump | 7.5kw |
| Dust collector | 5.5kw |
| Processing stroke | 1300*2500*220mm |
| Overall size | 2400*3500*2200mm |
